CNC Turning
CNC and manual lathes for round parts: shafts, bushings, pins, spacers and threaded work.
Turned parts, one or many
Our Milltronics CNC lathes run repeat parts consistently, and the manual lathe handles long shafts and quick one-off repairs. Turned parts can go straight on to milling, EDM, grinding or heat treat in the same shop.
- Shafts, pins, bushings, spacers and rollers
- Internal and external threads, grooves, tapers
- Bar work up to 2½" through the spindle
- Long work up to 60" between centers on the manual lathe
Size range
18.7"largest swing over the bed (CNC)
2½"spindle through-hole
60"between centers (manual lathe)
| Machine | Tool changer | Capacity |
|---|---|---|
| Milltronics ML18 CNC lathe | 8 positions | 18.7" swing over bed, 2½" spindle through-hole |
| Milltronics ML17 CNC lathe | 8 positions | 17" swing over bed, 2¼" spindle through-hole |
| Victor 1660 manual lathe | — | 16" swing, 60" between centers, 2" spindle through-hole |
Full list on the equipment page.
Need parts turned?
Send us your drawing or a description. One part or a production run, we'll get back to you with a quote.
